30W British amp with Top Boost modification

Schematic

Normal and Bright input channels where the Bright channel is enhanced with a further dual triode to increase gain and drive a tone stack. Note the Cut control reduces high frequency gain at the long tail pair phase splitter which can be useful to tame the boosted channel.

Click to enlarge
£29.00
